Impact-R 3083 - 57181801
Impact-R 3083 - PCI/PCIe, 3.0GHz Core i5-8500 (6C/6T) Base Kit Iss E
- Designed for harsh environments
- High quality industrial grade power supply
- Shock-mount drive bays
- Extensive burn-in factory testing
- 3 year warranty package
- Long life industrial motherboard designs
- 5 to 15 year lifecycle
Amplicon’s range of 3U systems provide the same expansion capabilities of a 4U with a 25% space saving. Our systems are built from industrial grade components and are ideal for any 24/7 critical application.
All of our Impact-R standard systems come backed with our 3 year warranty, with the first year being covered by an on-site next business day service.
All Impact-R models are based on the Intel® chipset technology providing integrated RAID 0, 1, 10, 5, and iAMT.
Amplicon's systems are able to offer 5~15 year life cycle.
6th generation to 10th generation processor options are available.
360 view available on Amplicon YouTube Channel
Windows 11 overview video available on Amplicon YouTube Channel
Learn more about the Amplicon Industrial Rackmount PC range.
- Chassis Size
- 3 U
- CPU
- Core i5
- Memory
- 8 GB
- OS Support
- Linux
- Windows 10
- Windows 10 IoT
- Expansion
- PCI
- M.2
- PCIe
- mPCIe
- Storage
- 1TB HDD
- CPU Cores (Physical)
- 6
- Chipset
- Intel® Q370
- Memory Type
- DDR4
- Max Operating Temperature
- 60 °C
- Mounting
- Rack
- CPU Generation
- 8th (Coffee Lake)
- Chassis depth
- Standard depth
- Max Memory
- 64 GB
- Brand
- Impact-R
- Impact-R 3083 Datasheet
- Datasheet 281.16 KB
- impact-r-roadmap
- Roadmaps 181.18 KB
